Boat Boarding Ramps

Passerelles, Swivel Side Mount, Ramp Angle Platform System

side mounted passerelle

Our RSP- 3G  vessel swivel side-boarding mount can be used with any of our 24" wide ramps. This mount will allow you to support the ramp from either side of your vessel and position the ramp forward, aft, or straight out from the side. (180 degrees swivel). It may also be mounted on the aft transom and allow the ramp to be extended to the port, starboard, or aft. When using our 3G swivel platform, you should through bolt the PCM or PSM mounts (using the included backing plates) to reduct the posibility of the mount pulling away from the vessel.

PAS-BBR   Rotating Flat Base platform Passerelle style mount  $2,990.00

RSP- 3G    Gen-3 Rotating swivel side platform Passerelle style mount   $2,990.00



New 2011 G-3 swivel side Mount Platform

G-3 side mount G-3 side mount G-3 G-3 G-3 G-3 side mount platform

                                 custom rail/gunnel mount on Marquis 59            custom rail/gunnel mount on Marquis 59          custom rail/gunnel mount on Marquis 59 w/ swivel platform

                                                                  Custom Rail/Gunnel Mount for a 59' Marquis

                                               8' ramp with swivel platform on a Marquis 59         8' ramp with swivel platform on a Marquis 59

                       8' ramp with swivel platform on a Marquis 59 (shown with optional gunnel mount. The system comes with standard PCM-Cam mount).



     passerelle side mount passerelle side mount passerelle side mount passerelle side mount

5800 Tiara w/ Side Mount and 10' ramp      5800 Tiara w/ Side Mount and 10' ramp

   5800 Tiara with a RSP side mount and 10'ramp w/Handrail             5800 Tiara with a RSP side mount and 10'ramp w/Handrail

custom gunwale mount      side mount

                Custom Gunwale saddle Mounts for the 5800 Tiara                                 RSP Side Mount on the 5800 Tiara

side mount      side with 10' ramp / no handrail

                       Side Mount                                                                         5800 Tiara with a RSP side mount and 10'ramp

side mount with ramp                              side mount, 10' ramp with handrail

5800 Tiara with a RSP side mount and 10'ramp                                5800 Tiara with a RSP side mount and 10'ramp w/Handrail

side mount      side mount with 10' ramp

         Side Mount  with Custom Gunwale saddle Mount                                    Side Mount with 10' ramp



New for 2013 is the RAP Ramp Angle Platform

Angle Platform Angle Platform

The RAP, Ramp angle platform will mount on the side or stern of your vessel and allow any of our ramps to be deployed from it at a 10 or 30 degrees angle. This will let you deploy the ramp on a finger dock or narrow walkway.  The RAP can be flipped over so that the angles will face either the bow or the stern if mounted on the vessel side or port/starboard if mounted on the stern. This platform does not swivel.

The RAP MSRP is $1,890.00







We can make adaptors that will allow our mounting system to adapt to your existing ladder or ramp mounts.

Our ramps are not designed to be cantilevered. They must be supported at both ends either with one of our mounting systems,or be resting on a surface or with a supporting “trapeze arrangement” that will support the wight of the ramp with several people on it.

Our flat base PAS-BBR manually deployed PASSERELLE style-boarding ramp has a flat base for mounting on a swim/dive platform or vessel deck. It can swivel 180 degrees horizontally side to side in and pivot up and down with the tide. It may be used with any of our 24" wide ramps. The flat base will be discontinued in 2014, we may still have some in stock. Please check with us if you are interested in this item.
